The SKF 6319M/C3VL0241 is a single-row deep groove ball bearing, with a 95mm inner diameter, 200mm outer diameter and 45mm width.
Industry Expertise
Global Reach
OEM/ODM Services
Product Introduction
Detailed Parameters
Message Us
The SKF 6319M/C3VL0241 is a single-row deep groove ball bearing, with a 95mm inner diameter, 200mm outer diameter and 45mm width. Its rings and rolling elements are made of high-carbon chromium bearing steel (AISI 52100), ensuring excellent hardness, wear resistance and fatigue strength. The M means a brass cage, C3 represents increased radial clearance, and VL0241 denotes electric insulation to prevent current damage.It handles moderate radial loads and light bidirectional axial loads, with stable operation at medium speeds. Widely applied in large electric motors, generators, pumps and wind turbine gearboxes, it excels in electrically charged industrial environments.
| BRAND | FONKIN/SKF/FAG/INA/NSK/NTN/TIMKEN/SNR/IKO/KOYO/ASAHI/FYH/THK/HIWIN/PMI |
| BEARINGS NO. | 6319M/C3VL0241-SKF |
| TYPE | Insulated bearings |
| Inner(d)mm | 95 |
| Outer(D)mm | 200 |
| Width(B)mm | 45 |
| WEIGHT/KG | 5.65 |
| EAN CODE | 7316571 429106 |
