The 3314A-2Z/C3 is a double-row angular contact ball bearing from SKF, featuring high-carbon chromium bearing steel (100Cr6) for rings and rolling elements, ensuring superior hardness, wear resistance and fatigue strength. The 2Z suffix means metal shields, while C3 denotes increased radial clearance for high-temperature environments.With a 70mm inner diameter and 150mm outer diameter, it handles combined radial and axial loads effectively. It is widely used in industrial gearboxes, textile machinery, printing equipment and small electric motors, delivering stable, low-noise operation under continuous working conditions.
| BRAND | FONKIN/SKF/FAG/INA/NSK/NTN/TIMKEN/SNR/IKO/KOYO/ASAHI/FYH/THK/HIWIN/PMI |
| BEARINGS NO. | 3314A-2Z/C3 SKF |
| TYPE | Angular Contact Ball Bearings |
| Inner(d)mm | 70 |
| Outer(D)mm | 150 |
| Width(B)mm | 63.5 |
| WEIGHT/KG | 5.05 |
| EAN CODE |
